Thông số kỹ thuật
| Model Name | DELTA-X12M |
| System Type | Passive |
| Configuration | Two-way |
| Frequency Response (+/-3dB) | 60-20kHZ |
| Frequency Range (- 10 dB) | 55-20kHZ |
| Sensitivity (2.83v/1m) | 97dB |
| Calculated Maximum SPL @1m | 129dB |
| System Rated Impedance | 8Ω |
| Low Frequency Transducer | |
| Size | 332mm / 12" Paper |
| Voice-Coil Size | 77.1mm / 3" |
| Rated Impedance | 8Ω |
| LF Power (re:AES2-2012) | 400W |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Voice-Coil Size | 50.8mm / 2" Titanium |
| Exit Size | 35.6mm / 1.4" |
| Diaphragm Material | Titanium |
| Rated Impedance | 8Ω |
| HF Power (re:AES2-2012) | 50W |
| Nominal Coverage (H x V) | 90⁰ x 45⁰ |
| Power | |
| System Continuous Power | 400W |
| System Programme Power | 800W |
| System Peak Power | 1600W |
| Crossover frequency | 1.8kHz |
| Input Connector | 2 x NL4 (speakON Compatible) |
| Hardware | |
| Handles | 2 on Sides |
| Enclosure | |
| Enclosure Material | 15mm Plywood |
| Finish | black paint |
| Grille Material & Finish | 1.5 mm Steel Black |
| Dimensions - Unpacked | |
| Height | 449(SITU)mm / 17.7" |
| Width Front | 390mm / 15.4" |
| Width Rear | 390mm / 15.4" |
| Depth | 618mm / 24.3" |
| Dimensions - Packed | |
| Height | 462mm / 18.2" |
| Width Front | 690mm / 27.2" |
| Width Rear | 690mm / 27.2" |
| Depth | 522mm / 20.6" |
| Weight | |
| Net Weight (kg / lbs) | 23.18kg / 50.9lbs |
| Gross Weight (kg / lbs) | 28.5kg / 62.7lbs |
 Hướng dẫn sử dụng (Tiếng Anh) |
|
Loa PA Passive Wharfedale Pro DELTA-X12M Monitor - Hàng Chính hãng PGI
23.800.000đ
Loa monitor sân khấu 12"
Loa HF nén 2” từ Titan
Công suất cực đại 1200W
Max SPL 129dB
Chế độ hoạt động Bi-amp hoặc Passive
